Project Description
AK RAM PUMP SERIES + (Full Two Post Drum Type)
PNEUMATIC AIRLESS PUMP HIGH VISCOSITY COATINGS
Description
High flow rates and high fluid pressures increase production rates
High output per cycle reduces wear for longer life and lower repair costsIdeal for spraying hot-potted PFP epoxy
Powerful Check-mate type pump
Easy maintenance
Highly efficient air motor
Ideal for high-viscosity coatingsApplication
• Typical fluids handled
• Mastics
• Inks
• Adnesive
• Seaknts
• Lubricants
| TECHNICAL DATA | AKL-651 |
|---|---|
| FLUID PRESSURE RATIO | 65:1 |
| DELIVERY(LITER)/MIN | 12 |
| CC PER CYCLE | 200 |
| MAX. PUMP SPEED / MIN | 60 |
| AIR MOTOR DIAMETER(INCH;MM) | 10(254) |
| STROKE LENGTH(MM) | 127 |
| AIR POWERED RANGE(BAR) | 1-7 |
| MAXIMUM PRESSURE(PSI;BAR) | 6599(455) |
| SIZE | 1,060x620x1,585mm |
| MAX HEIGHT | 2,650mm |
| WEIGHT | 268kg |
